12326EN
Xtreme

XTREME, 4 x 6 model - EN 131 - 150 kg rated, aluminum articulated extendable ladder with trestle brackets

Download Media Package

  • Model Number: 10069 - ADJUSTABLE PLANK, 6-9-Foot model, 250 lb one person rated, aluminum ladder accessory
  • Model Number: 10104TUV - Work Platform, EN131, accessory for articulated extendable ladders
  • Model Number: 10111 - WingSpan Wall Standoff
  • Model Number: 10154EN - Work Platform, EN131, Adjustable, accessory for articulated extendable ladders
  • Model Number: 10813 - ADJUSTABLE PLANK, 8-13-Foot model, 250 lb one person rated, aluminum ladder accessory
  • Model Number: 10915 - ADJUSTABLE PLANK, 9-15-Foot model, 250 lb one person rated, aluminum ladder accessory
  • Model Number: 15036 - PLANK, 6-Foot Model, 500 lb two person rated, aluminum ladder accessory
  • Model Number: 15040-001 - Cargo Hold
  • Model Number: 15049 - Accessory pack, AIRDECK workstation and Ladder Rack
  • Model Number: 15050-001 - Fuel Tank
  • Model Number: 15089 - Accessory pack, WINGSPAN wall standoff and Ladder Rack
  • Model Number: 15097 - Ladder Rack
  • Model Number: 15180 - PLANK, 8-Foot Model, 500 lb two person rated, aluminum ladder accessory
  • Model Number: 15210 - PLANK, 10-Foot Model, 500 lbs two person rated, aluminum ladder accessory
  • Model Number: 26057 - AirDeck Workstation
  • Model Number: 26999 - Trestle Brackets - Most multi-position models
  • Model Number: 26057 - AirDeck Workstation
  • Model Number: 26260 - Trestle Brackets, accessory for the the REVOLUTION, QUANTUM, XTREME, LT, DEFENDER, and the VELOCITY ladder made after July 1st, 2015

Xtreme™

If you are looking for a ladder that exudes versatility, the Little Giant® Xtreme™ is the ladder you need. Over 40 years of engineering helped us create this signature ladder to help you successfully complete every project, both in the house and on the job. The Xtreme is available in 17’, 22’ and 26’ models. This Type IA ladder is rated to hold 300 lbs., and when placed in A-frame, is rated to hold 300 lbs. on both sides. The Xtreme meets or exceeds all OSHA and ANSI standards.



Multi-Position Ladder

If you need to reach a high place, get close to your task or work on a staircase, the Xtreme can help you get there. This articulating, multi-position ladder converts to A-frame, extension, trestle-and-plank*, 90-degree and staircase with the press of a button. You are going to love how seamless it is to transition from project to project with the Xtreme.



Ratchet™ Levelers

You may have seen the Ratchet™ leg levelers before, but nothing beats experiencing them firsthand. Working outside comes with its challenges, with uneven surfaces being the foremost concern. The Ratchet leg levelers allow you to adjust the ladder’s legs independently to securely reach uneven ground, quickly stabilizing your ladder.



Compatibility

It is important that your ladder is compatible with ladder accessories. Whether you are using the AirDeck™, Work Platform or Safety Rails, the Xtreme can handle it.



When used with the Safety Rails, you can convert your ladder’s extension orientation to an even safer, sturdier workspace. The Safety Rails can be placed horizontally or vertically on the Xtreme ladder. When placed horizontally, it spans windows. In its vertical orientation, it creates a safe walkthrough for you to move from ladder to rooftop. Make your ladder more comfortable and convenient with these unique accessories.



Wherever the job may take you, the Xtreme is going to be the ladder that you will want to take with you.



*Plank not included.

Specifications
Product Category Xtreme
Extension Lock Plastic Rock Locks
Country Assembled China
Marketing Language Europe
Duty Rating Type IA - Extra Heavy Duty
Feet Standard non-marring (snap-on)
Hinge Lock Plastic / Quad Lock
Material Aluminum
Load Capacity 300 lbs.
90° Ladder Yes
Scaffolding Position Yes
Spreader System Hinge Lock
Tip-N-Glide Wheels No
Ladder Type Telescoping - Articulated
Warranty Limited Lifetime
Size 13' - 23' 3.96 m - 7.01 m
Inside Clear Width 1 ft. 32 cm
Storage Height 6 ft. 7 in. 2.01 m
Storage Width at Base 2 ft. 6 in. 76 cm
Storage Depth 9 in. 23 cm
Inner Rung Depth 1 in. 4 cm
Outer Rung Depth 1 in. 4 cm
Double Rung Depth 3 in. 9 cm
Top Width 1 ft. 6 in. 46 cm
Product Weight 68 Lbs.
Shipping
Freight Class 250 - Ladders and/or Accessories
Ship Length 80"
Ship Width 31"
Ship Height 9"
Ship Weight 76.4 Lbs.
HTS Code 7616.99.5190
Step Ladder
Highest standing level Max 9 ft. 6 in. 2.90 m
Highest standing level Min 4 ft. 10 in. 1.47 m
Maximum Footprint 8 ft. 3 in. 2.51 m
Minimum Footprint 4 ft. 9 in. 1.45 m
Max Reach 16 ft. 4.88 m
Single / Extension
Extension Total Length of Sections 25 ft. 2 in. 7.67 m
Extension Max Reach 25 ft. 6 in. 7.77 m
Single / Extension Highest Standing Level Max 19 ft. 4 in. 5.89 m
Single / Extension Highest Standing Level Min 9 ft. 9 in. 2.97 m
Single / Extension Max Working Length 22 ft. 11 in. 6.99 m
Single / Extension Min Working Length 12 ft. 11 in. 3.94 m
