12717
Quantum

QUANTUM, Model 17 - ANSI Type IA - 300 lb Rated, Aluminum Articulated Extendable Ladder

Download Media Package
Download Box Label
Download Notice Label

No manuals have been assigned to this product

  • Model Number: 10104 - Work Platform
  • Model Number: 10111 - WingSpan Wall Standoff
  • Model Number: 10116 - Accessory pack, WINGSPAN Wall Standoff and Work Platform, Accessories for Articulated Extendable Ladders
  • Model Number: 11069 - ADJUSTABLE PLANK, 6-9-Foot Model, 500 lb two person Rated, Aluminum Ladder Accessory
  • Model Number: 11813 - ADJUSTABLE PLANK, 8-13-Foot Model, 500 lb Two Person Rated, Aluminum Ladder Accessory
  • Model Number: 11915 - ADJUSTABLE PLANK, 9-15-Foot Model, 500 lb two person Rated, Aluminum Ladder Accessory
  • Model Number: 15012 - Project Tray
  • Model Number: 15036 - PLANK, 6-Foot Model, 500 lb Two Person Rated, Aluminum Ladder Accessory
  • Model Number: 15040-001 - Cargo Hold
  • Model Number: 15048 - Accessory pack, Ladder Rack and Work Platform
  • Model Number: 15050-001 - Fuel Tank
  • Model Number: 15086-001 - Accessory pack, QUANTUM STEP Platform and FUEL TANK vertical paint tray
  • Model Number: 15087 - Accessory pack, Work Platform and Project Tray, Accessories for Articulated Extendable Ladders
  • Model Number: 15089 - Accessory pack, WINGSPAN wall standoff and Ladder Rack
  • Model Number: 15097 - Ladder Rack
  • Model Number: 15180 - PLANK, 8-Foot Model, 500 lb two person Rated, Aluminum Ladder Accessory
  • Model Number: 15210 - PLANK, 10-Foot Model, 500 lb Two Person Rated, Aluminum Ladder Accessory
  • Model Number: 26057 - AirDeck Workstation
  • Model Number: 26057-001 - Airdeck Workstation
  • Model Number: 26999 - Trestle Brackets - Most multi-position Models

Quantum®



The Quantum® from Little Giant® is made from lightweight aluminum and is easy to use, so you can focus on getting stuff done.



Multi-Position Ladder

This ladder is a multi-position ladder, meaning, you can set it up in different configurations that suit the project at hand. Use the Quantum as a stepladder or extension. Set it up on staircases or in 90-degree or trestle-and plank* scaffolding configurations. With the sleek metal palm buttons, you will be able to effortlessly adjust your ladder.



Adjustable Ratchet™ Leg Levelers

With the optional attached Ratchet™ levelers, you can adjust the ladder’s legs in a hands-free motion in seconds. The retractable legs yield more than 7 inches of leveling adjustment, so you can have a stable ladder, regardless of the terrain.



Accessory Ports

The Quantum is compatible with select accessories offered by Little Giant Ladder Systems®, like the AirDeck® workstation and the Quantum Step™.



Specs

Meeting or exceeding all OSHA and ANSI standards, the Quantum is a Type IA ladder rated to hold 300 lbs.



*Plank not included.



Specifications
Product Category Quantum
Extension Lock Rapid Lock
Country Assembled China
Marketing Language English / Spanish
Duty Rating Type IA - Extra Heavy Duty
Feet Standard non-marring (snap-on)
Hinge Lock None
Material Aluminum
Load Capacity 300 lbs.
Spreader System Hinge Lock
Ladder Type Telescoping - Articulated
Warranty Limited Lifetime
Size 9' - 18' 1" 2.74 m - 5.51 m
Inside Clear Width 1 ft. 32 cm
Storage Height 4 ft. 8 in. 1.44 m
Storage Width at Base 2 ft. 61 cm
Storage Depth 9 in. 23 cm
Inner Rung Depth 1 in. 4 cm
Outer Rung Depth 1 in. 4 cm
Double Rung Depth 3 in. 9 cm
Top Width 1 ft. 6 in. 46 cm
Product Weight 34 lbs. 15.42 kg
Features
Scaffolding Position Yes
Tip-N-Glide Wheels Yes
90° Position Yes
Shipping
Freight Class 250 - Ladders and/or Accessories
HTS Code 7616.99.5190
Step Ladder
Stepladder Size 4' 6" - 7' 6" 1.37 m - 2.29 m
Highest standing level Max 5 ft. 9 in. 1.75 m
Highest standing level Min 2 ft. 11 in. 89 cm
Maximum Footprint 5 ft. 2 in. 1.58 m
Minimum Footprint 3 ft. 4 in. 1.03 m
Max Reach 12 ft. 3 in. 3.73 m
Single / Extension
Extension Total Length of Sections 17 ft. 2 in. 5.23 m
Extension Max Reach 18 ft. 1 in. 5.51 m
Single / Extension Highest Standing Level Max 11 ft. 7 in. 3.53 m
Single / Extension Highest Standing Level Min 5 ft. 9 in. 1.75 m
Single / Extension Max Working Length 14 ft. 11 in. 4.55 m
Single / Extension Min Working Length 8 ft. 11 in. 2.72 m
