18503-240
Cage-Adjustable

CAGE, 3'-5' Model - ANSI Type IAA - 375 lb Rated, Fiberglass Adjustable Enclosed Elevated Platform with Wheel Lift

Dowload Specsheet
Download Media Package
Download Box Label
Download Notice Label

  • Model Number: 15072 - Saddle Bag
  • Model Number: 15074 - CAGE TIP & GLIDE/Side-Tip Wheels
  • Model Number: 15076 - CAGE Wheel Lift Kit
  • Model Number: 15074 - CAGE TIP & GLIDE/Side-Tip Wheels
  • Model Number: 15076 - CAGE Wheel Lift Kit

Adjustable Safety Cage™

Many industries require professionals to tie off at an anchor point when working at certain heights. This standard helps keep people safe, but it can be a difficult standard to maintain. The OSHA-compliant Little Giant® Adjustable Safety Cage™ eliminates the need to tie-off, making jobs faster, safer, and less expensive than many scaffolding options.



GUARDRAIL SYSTEM

The fully enclosed guardrail system on the Adjustable Safety Cage eliminates tie-off requirements.



WHEEL LIFT

Wheel Lift casters allow for safe, easy movement, even when Adjustable Safety Cage is fully deployed.



ADJUSTABLE OUTRIGGERS

Adjustable outriggers increase the footprint of the Cage, adding additional side-tip stability



Specifications
Product Category Cage-Adjustable
Extension Lock Cast Aluminum Rock Locks
Country Assembled USA
Marketing Language English / Spanish
Duty Rating Type IAA - Special Duty
Feet Standard non-marring (snap-on)
Hinge Lock None
Material Fiberglass
Load Capacity 375 lbs.
Spreader System Platform
Ladder Type Cage - Telescoping Platform
Warranty 1-Year
Size 3' - 5' 91 cm - 1.52 m
Inside Clear Width 1 ft. 8 in. 52 cm
Storage Height 7 ft. 10 in. 2.39 m
Storage Width at Base 3 ft. 10 in. 1.17 m
Storage Depth 1 ft. 5 in. 43 cm
Inner Rung Depth 1 in. 4 cm
Outer Rung Depth 1 in. 4 cm
Double Rung Depth 3 in. 10 cm
Top Width 2 ft. 2 in. 66 cm
Product Weight 102 lbs. 46.26 kg
Features
Scaffolding Position No
Tip-N-Glide Wheels Yes
90° Position No
Cage
Kick Plate Height 3 in. 9 cm
Mid Rail Height 1 ft. 10 in. 57 cm
Guardrail Height 3 ft. 9 in. 1.14 m
Shipping
Freight Class 300 - AL and/or FG Ladder
HTS Code 3926.90.9930
Step Ladder
Stepladder Size 3' - 5' 0.91 m - 1.52 m
Highest standing level Max 4 ft. 11 in. 1.50 m
Highest standing level Min 3 ft. 91 cm
Maximum Footprint 5 ft. 11 in. 1.80 m
Minimum Footprint 3 ft. 9 in. 1.14 m
Max Reach 11 ft. 5 in. 3.48 m
